Description
UNI-T Classic thermal imagers are designed with international thermal sensors. The refined functions and good video performance are user friendly. The rugged product design IP65 and 2m drop tests.These series products are rugged, and ergonomically designed thermalimager with great performance. It adopts a UFPA detector to ensureexcellent infrared resolution and a rich variety of palette modes.Some models have the functions of visual light, buzzer alarm, andreal-time image transmission, which is convenient for various applications.
Features：
● 2.8" TFT screen ● Infrared resolution: 80 x 60 to 256 x 192
● Temperature measurement range: -15℃~550℃
● Photograph function with SD card storage
● PC analysis software
● Buzzer/flashlight alarm
● Real-time image transmission
● Auto capture of Hi/Low temperature
● Flashlight
● 1/4" tripod mounting hole
● IP65/2m drop proof
● Temperature measurement range: -15℃~550℃
● Photograph function with SD card storage
● PC analysis software
● Buzzer/flashlight alarm
● Real-time image transmission
● Auto capture of Hi/Low temperature
● Flashlight
● 1/4" tripod mounting hole
● IP65/2m drop proof
Techincal Specification:
| Specifications | |||||
| Model | UTi85A | UTi120B | UTi165A | UTi220B | UTi260B |
| Certifications | CE/RoHS | ||||
| Temperature range | -10~400℃ | -10~400℃ | -10~400℃ | -10~400℃ | -15~550℃ |
| IR resolution | 80x60 pixels | 120x90 pixels | 160x120 pixels | 200x150 pixels | 256x192 pixel |
| Field of view (FOV) | 51°x38° | 51°x38° | 56°x 42° | 35°x26° | 56°x 42° |
| Thermal sensitivity (NETD) | 150mK | 60mk | 50mk | 100mk | 50mk |
| Spatial resolution (IFOV) | 11.1mrad | 7.3mrad | 6.1mrad | 3.1mrad | 3.8mrad |
| Frame rate | 9Hz | 25Hz | 9Hz | 9Hz | 25Hz |
| Measurement accuracy | ±2℃ or ±2% whichever is greater | ||||
| Palettes | 5 | 7 | 5 | 7 | 7 |
| Emissivity | Adjustable (0.01-1) | Adjustable (0.01-1) | Adjustable (0.01-1) | Adjustable (0.01-1) | Adjustable (0.01-1) |
| Focus | Focus free | Focus free | Focus free | Focus free | Focus free |
| Display modes | Thermal | Thermal, blending, visible | Thermal | Thermal, visible, blending | Thermal, blending, visible, PIP |
| Display | 2.8”LCD | 2.8”LCD | 2.8”LCD | 2.8”LCD | 2.8”LCD |
| ROI (eliminates interference) | √ | √ | √ | √ | |
| General Characteristics | |||||
| Power | Li-ion battery (3.6V 5000mAh) | ||||
| Product net weight | Around 910g | ||||
| Product net size | 236mm x 75.5 mm x 86mm | ||||
| Standard accessories | Micro SD card, Type-C USB cable, English manual | ||||
| Standard individual packing | Gift box | ||||
| Standard quantity per carton | 10pcs | ||||
| Standard carton measurement | 610mm x 345mm x 305mm | ||||
| Standard carton gross weight | 10.1kg | ||||
